High capacity. Low operating costs. Easy maintenance.
BioMax combines a heavy-duty pelleting chamber with a stand-alone gearbox and patented material infeed. The result is consistent, high-capacity performance for demanding workloads.
BioMax Pellet Mill
Key features and benefits
- Unique patented infeed
Optimized material distribution for maximum throughput and superior pellet quality. - Hydraulic roll adjustment
Fast, precise roll positioning for efficient operation and simplified maintenance. - Reversible taper-fit die
Extended die lifetime with quick replacement and lower operating costs. - Built-in overload protection
Protects key components automatically, helping reduce downtime and increase equipment reliability.
Technical specifications
| Main motor | Up to 800 kW, 50/60 Hz |
| Die | 1,200 mm (inner diameter) |
| Effective press width | 190 mm |
| Effective press area | 0.72 m² |
| Inlet screws | Stainless steel, 3 × 1.5 kW |
| Total weight | 33,000 kg (including main motor and screw feeder) |
